¡¡ IFeatures
128x64 graphic LCD.
2 SIP accounts.
Support Communication app EP+.
Adjustable bracket.
Support PoE, Auto-provision.
¡¡Phone Features
2 SIP accounts, MWI(Line1)
Call hold, Call waiting, Call forward, Call return; Call transfer (blind/busy/ask)
Caller ID display, Redial, Mute, DND
Auto-answer, 3-way conferencing
Speed dial, SMS, Voicemail
Tone scheme, Volume control
Direct IP call without SIP proxy
Ring tone selection/import/delete
Black list, Hand-free indicator.
Call history: dialed/received/missed (50 -entries);
Soft keys programmable, Supports PC control
Multi-Language: Chinese,English,French,Russian,
Italian,Polish,
Portuguesa,Portuguesa-Brasil,Spanish,Turkish
Advanced Features
5 programmable keys
XML Phone Book search and input & output
Enterprise phone book(800 entries)
LDAP phone book
IP PBX System Integration
Busy lamp field (BLF), BLF list
Bridged line appearance (BLA)
DND & Forward synchronization
Intercom, Paging, Music on hold
Call pickup, Dial Plan, Call recording
Anonymous call, Anonymous
call rejection
Network conference, Distinctive ring tone
Codes and Voice Features
Wideband Codec: G.722
Narrowband codec: G.711¦Ì/A, G.723.1
G.726, G.729AB,iLBC
VAD, CNG, AEC, AGC, Full-duplex
Security
VLAN QoS (802.1pq)
Phone lock for personal privacy protection
Admin/User 2-level configuration mode ,
LLDP, CDP
L2TP VPN tunneling protocol - added
Network Features
SIP v1 (RFC2543), v2 (RFC3261)
SIP connection: Proxy mode & Peering
Points mode;
¡¡DNS SRV (RFC3263);
Redundant server support
NAT Traversal: STUN mode
DTMF: In-Band, RFC2833, SIP Info, Auto
HTTP/HTTPS Web Management
IP Assignment: Static/DHCP/PPPoE
Bridge/Router mode for PC port
TFTP/DHCP/PPPoE client
DNS client, NAT/DHCP server
Layer 3 ToS, DSCP
Management
Auto-provision via FTP/TFTP/HTTP/HTTPS
SNMP V1/2
Configuration: browser/phone/auto-provision
Trace package and system log export
Physical Features
128*64 graphic LCD with back light
25 keys, including 5 programmable keys,
2 LEDs: 2* account lights, including MWI(L1)
1* RJ9 handset port
2xRJ45 10/100M Ethernet ports
Power adapter: AC 100~240V input and
DC 5V/1A output
Power over Ethernet ,IEEE 802.3af,class 0(Option)
Power consumption: 1.5W
Net weight: 0.62kg
Dimension: 213*157*39mm
Operating humidity: 10~95%
Storage temperature: up to 60¡ãC
Package Features
Qty/CTN: 10 PCS
N.W/CTN: 6.2kg
G.W/CTN: 8.5kg
Carton Meas: 430x345x250mm
