Features
132x64 graphic LCD.
3 SIP accounts, Gigabit (ES330-PEG).
Support Communication app EP+.
15 Paperless Programmable keys.
6 Expansion Modules up to 192 keys.
12 Programmable keys (paper)
Adjustable bracket, wall-mountable.
Support Bluetooth, EHS, USB Charging, PoE.

¡¡

Phone Features 3 SIP accounts, Hotline Call hold, Call waiting, Call forward, Call return Call transfer (blind/busy/ask) Caller ID display, Redial, Mute, DND Auto-answer, 3-way conferencing Speed dial, SMS, Voicemail Message Waiting Indication LED Tone scheme, Volume control Direct IP call without SIP proxy Ring tone selection/import/delete Black list, Hand-free indicator. Call history: dialed/received/missed (50 -entries); Multi-Language Soft keys programmable, Supports PC control Advanced Features XML Phone Book search and input & output Enterprise phone book(800 entries) LDAP phone book Functions customizable keys Support up to 15 paperless programmable keys IP PBX System Integration Busy lamp field (BLF), BLF list Bridged line appearance (BLA) DND & Forward synchronization Intercom, Paging, Music on hold Call pickup, Dial Plan, Call recording Anonymous call, Anonymous call rejection Network conference, Distinctive ringtone Codes and Voice Features Wideband Codec: G.722 Narrowband codec: G.711¦Ì/A, G.723.1 G.726, G.729AB,iLBC VAD, CNG, AEC, AGC, Full-duplex, Security VLAN QoS (802.1pq) Phone lock for personal privacy protection Admin/User 2-level configuration mode , LLDP, CDP L2TP VPN tunneling protocol - added Network Features SIP v1 (RFC2543), v2 (RFC3261) SIP connection: Proxy mode ; Peering Points mode;

DNS SRV (RFC3263);
Redundant server support
NAT Traversal: STUN mode
DTMF: In-Band, RFC2833, SIP Info, Auto
HTTP/HTTPS Web Management
IP Assignment: Static/DHCP/PPPoE
Bridge/Router mode for PC port
TFTP/DHCP/PPPoE client
DNS client, NAT/DHCP server
Layer 3 ToS, DSCP

Management
Auto-provision via FTP/TFTP/HTTP/HTTPS
SNMP V1/2
Configuration: browser/phone/auto-provision
Trace package and system log export

Physical Features
132x64 graphic LCD
50 keys, including 12 programmable keys
23 LEDs:
1* headset light
3* account lights
1* message light
1* headset light
12*programmable lights
4* function lights
1* speaker lights
Wall-mountable
1* RJ-9 handset port
1*RJ-9 headset port
1*3.5mm PC headset port
2xRJ45 10/100/1000M Ethernet ports
WIFI 5.8GHz
Power adapter: AC 100~240V input and
DC 12V/1A output
USB only support DC 5V feature.
Power over Ethernet ,IEEE 802.3af,class 0
Power consumption: 2.5-3.5W
Net weight: 1.2KG
Dimension: 287x214x90MM
Operating humidity: 10~95%
Storage temperature: up to 60¡ãC

Package Features
Qty/CTN: 10 PCS
N.W/CTN: 12KG
G.W/CTN: 15.24KG
Carton Meas: 485*460*300MM ¡¡
